Technical Parameters:
0.5~1.5mm2(22-16)Imax=19A
1.5~2.5mm2(16~14)Imax=27A
Item No
USA screw
Screw dia.d2(mm)
Dimension(mm)
Color
B
L
F
H
Dφ
RV 1.25-3
#4
3.2
5.7
17.8
4.95
10.0
4.3
red
RVS1.25-3.5
#6
3.7
5.7
17.8
4.95
RVM1.25-3.5
#6
3.7
6.6
20.1
6.3
RVL1.25-3.5
#6
4.3
8.0
21.5
7.0
RVS1.25-4
#8
4.3
6.6
20.1
6.3
RVL1.25-4
#8
4.3
8.0
21.5
7.0
RV1.25-5
#10
5.3
8.0
21.5
7.0
RVL1.25-5
#10
5.3
9.8
23.0
8.5
RV1.25-6
1/4
6.4
9.8
23.0
8.5
RVS1.25-6
1/4
6.4
11.6
27.5
11.1
RV1.25-8
5/16
8.1
11.6
27.5
11.1
RV1.25-10
3/8
10.5
13.6
31.6
13.9
RV1.25-12
1/2
13.0
19.2
36.0
16.5
Item No
USA screw
Screw dia.d2(mm)
Dimension(mm)
Color
B
L
F
H
Dφ
RV2-3
#4
3.2
6.6
17.8
4.3
10.0
4.3
Blue
RVS2-3.5
#6
3.7
6.6
17.8
4.3
RVM2-3.5
#6
3.7
6.6
21
7
RVL2-3.5
#6
4.3
8.5
22.5
7.75
RVS2-4
#8
4.3
6.6
21
7
RVL2-4
#8
4.3
8.5
22.5
7.25
RVS2-5
#10
5.3
8.5
22.5
7.25
RVL2-5
#10
5.3
9.5
22.5
7.25
RV2-6
1/4
6.5
12
27.6
11
RV2-8
5/16
8.4
12
27.6
11
RV2-10
3/8
10.5
13.6
30.2
13.9
RV2-12
1/2
13
19.2
36.5
16.5
2.5~4mm2(14~12)lmax=37A
Item No
USA screw
Screw dia.d2(mm)
Dimension(mm)
Color
B
L
F
H
Dφ
RV3.5-4
#6
3.7
8
24.5
7.7
12.5
6.2
Black
RVS3.5-5
#8
4.3
8
24.5
7.7
RVL3.5-5
#8
4.3
12
27.9
7.7
RV3.5-6
#10
5.3
12
27.9
7.7
4~6mm2(12~10)Imax=48A
Item No
USA screw
Screw dia.d2(mm)
Dimension(mm)
Color
B
L
F
H
Dφ
RV5.5-3.5
#6
3.7
7.2
21.4
5.9
12.5
7.2
Yellow
RVS5.5-4
#8
4.3
7.2
21.5
5.9
RVL5.5-4
#8
4.3
9.5
25.5
8.3
RV5.5-5
#10
5.3
9.5
25.5
8.3
RV5.5-6
1/4
6.5
12
31.5
13
RV5.5-8
5/16
8.4
15
33.7
13.7
RV5.5-10
3/8
10.5
15
33.7
13.7
RV5.5-12
1/2
13
19.2
38.1
16
Outline Overall and Installation Dimensions (mm):
