Technical Parameter：
|
Type |
ADM-V96 |
ADM-V72 |
ADM-V48 |
ADM-V36 |
|
Operating Voltage(Un) |
140V~260V AC |
|||
|
Operating Frequency |
50/60Hz |
|||
|
Operating Power |
<6AV |
|||
|
Operating Temperature |
0℃~55℃ |
|||
|
Voltage Measurement Range |
1V~500V AC |
|||
|
Measurement Precision |
±1% |
|||
|
Display |
20mm 3 digit display |
14mm 3 digit display |
9mm 3 digit display |
14mm 3 digit display |
|
Connection Type |
Plug-in terminal |
|||
|
Cable Diameter |
1.5m㎡ |
|||
| Weight |
<200g |
|||
|
Panel Hole Sizes |
91mm×91mm |
68mm×68mm | 45mm×45mm | 30mm×72mm |
|
Mounting |
Front panel mounted |
|||
|
Protection Calss |
IP20 |
|||
|
Operating Altitude |
<2000m |
|||
Outline dimension&WiringDiagram：
