1、Two Integral Current Transformers
2、Under-Current protection
3、Wide Current Range
4、Manual / Electric Reset
5、Low Energy Consumption
6、R Type(Non-fail-safe)
Ordering requirements：
Protection：
|
Protective Item |
Trip Time |
|
Under-current |
O-TIME |
Technical Parameters：
|
Current Setting
|
Type
|
Range
|
|
|
05 |
0.5～6A |
||
|
30 |
3～30A |
||
|
60 |
5～60A |
||
|
60～600 |
Use an external CT(secondary 5Ajover 60A with 05 type.
|
||
|
TIME
|
Operating
|
O-TIME
|
0.2～30 sec |
|
Recovery
|
R-TIME
|
0.2～120 sec/OFF |
|
|
Reset
|
Manual /Electric Reset
|
||
|
Indicator
|
LED |
||
|
Control Voltage
|
Voltage range
|
S(Premium) |
24V~240V AC/DC |
|
W(Premium) |
180~460V AC |
||
|
Frequency
|
50/60Hz |
||
|
Output
|
Contact
|
2-SPDT (1a1b) |
|
|
Condition
|
R Type
|
When powered,95+十96 Close,97+F98 Open
|
|
|
Humidity
|
30～85%RH,Not-condensate
|
||
|
Mounting
|
35mm DIN-Rail /Pane
|
||
Outline and Installation Dimensions：
